在轉速1200RPM. 粘度32MM²/S下的測量值 4kgf/cm² ~ 70kgf/cm² DVS※-1V = 6.4 ~ 1.4 DVS※-2V = 9.0 ~ 1.7 DVS※-3V = 13.5 ~ 2.4 DVS※-4V = 19.5 ~ 3.2 DVS※-5V = 33.0 ~ 4.9 DVS※-6V = 43.0 ~ 6.2

Delivery (l/min) 4kgf/cm² ~ 70kgf/cm² DS11P = 5.0 ~ 1.1 DS12P = 7.7 ~ 1.5 DS13P = 12.6 ~ 2.1 DS14P = 22.1 ~ 3.4

When the pressure is under 140kgf/cm2, 1200rpm, the noise level of DP10 series pump is lower than 70 dBa. When pressure is under175 kgf/cm2, 1800rpm, its output flow rate of DP200 series is from 125 to 191.5 l/min.

A0: 10 ~ 40 A1: 20 ~ 70 A2: 30 ~ 140 A3: 40 ~ 210 A4: 40 ~ 250

A1: 8 ~ 70 A2: 15 ~ 140 A3: 20 ~ 210 A4: 20 ~ 250

SOL “OFF” = 15 ~ 18 SOL “ON” = A: 15 ~ 35 kgf/cm² B: 20 ~ 70 kgf/cm² C: 50 ~ 105 kgf/cm² D: 70 ~ 140 kgf/cm²

Displacement range is from 20cc to 86cc (at 1800rpm) There’re 2 adjustable types: Standard and remote control type. ADJUSTING PRESSURE RANGE GF/CM² A: 15 ~ 35 kgf/cm² B: 20 ~ 70 kgf/cm² C: 50 ~ 105 kgf/cm² D: 50 ~ 140 kgf/cm²

Maximum pressure is 210kgf/cm2 Widely displacement range from 8cc to 237cc. High efficiency, stabilize when high pressure operation. Low unpleasant noise, low vibration. Output flow stabilize with high pressure. High efficiency operation with low motor power-loss.

Displacement range of 50T is from 7cc to 40cc Displacement range of 150T is from 48cc to 125cc Displacement range of GPEON is from 3cc to 11cc. They are widely used as a source of hydraulic power. Maximum pressure of 50T/150T is 70 kgf/cm2 Maximum pressure of GPEON is 210 kgf/cm2

Hydraulic double pump Displacement range of 50T is from 7cc to 40cc Displacement range of 150T is from 48cc to 125cc Displacement range of VF is from 6cc to 31cc. They are widely used as a source of hydraulic power. Maximum pressure of 50T/150T is 70 kgf/cm2 Maximum pressure of VF is 210 kgf/cm2

A: 8 ~ 18 kgf/cm² B: 15 ~ 35 kgf/cm² C: 30 ~ 55 kgf/cm² D: 50 ~ 70 kgf/cm² GPEON 2, 3, 4, 6, 7.5, 8.8, 10, 11.5 c.c.
